bu32oil filter

bu32oil filter


报价:  电议
单位: 厦门利佰优机电科技
姓名: 罗先生
电话: 0592-7019203

he oil cleaner is designed with bypass filtation system.The oil coming from the hydraulic pump flow through a specially designed throttle valve which distributes a certain amount of oil to the CGL oil cleaner for accurate filtration.After filtrated,the clean oil return to oil tank.The oil cleaner ensures a constant oil circulation continuously.It does not require a routine maintenance in addition to periodic replacement of filter core .The more frequent of hydraulic pump running,the more cleanof oil.It keeps oil clean at all times FEATURES:
<1>.The oil cleanner uses machine power without need of other additional power.
<2>.Light weight,compact construction,convenient installation and requeires only small installation space.。
<3>.Employs specially designed throttle valve for maximum stability of oil flow,which assures superior filtration accuracy and efficiency(accuracy up to class NAS 6-9).
<4>.sUITABLE FOR ALL HYDRAULIC MACHINES WITH PRESSURE RANGE 10-210kgf/cm2。
<5>.Easy to maintain。
MODEL
BU32
BU50
BU100
Applicable oil
Hyd,ad lubr.Oil etc.
Filtration accuracy
From NAS class12 to NAS class6-9(1pass)
Pressure range
10~210kgf/cm2
Flow amount(L/min)
1.0
1.5
2.0
Oil temp
0~80℃
Viscosity Range
9~180cSt
In/out port
IN.RC1/4,OUT.G3/8
Prs gauge
φ40,0~10kgf/cm2
Weight
2.5Kg
4.0 Kg
6.5Kg
Oil tank cap
Max300L
Max500L
Max1000L


规格:  bu32
数量:   包装:
日期:  2014-02-24
